S355J2W corten steel, S355J2W corten steel plate specification

S355J2W corten steel, S355J2W corten steel plate specification

S355J2W is weather resistant steel which is intended for use in load bearing or heavy structures due to its greater tested impact strength. It is also suitable for low temperature working environments.

Like all weather resistant steels, S355J2W is self protecting – the material rusts over time due to the reaction with chemical elements in the air. This rust layer acts a protective barrier which prevents further oxidation. The steel is economical to use and is fully recyclable. As a structural steel it is can be used as easily for load bearing duties as it can for purely cosmetic purposes.

S355J2W corten steel plate specification:
Thickness: 6mm to 300mm,
Width: 1500mm to 4050mm,
Length: 3000mm to 15000mm

S355J2W corten steel

Grades & Equivalents:

EN 10025-5:2004

Corten

S355J2W

Corten B

S355J2W corten steel chemical composition:

Grade

C

Si

Mn

P

S

N

Addition of
nitrogen binding
elements

Cr

Cu

S355J2W

0.16

0.50

0.50/1.50

0.030

0.030

0.009

0.40/0.80

0.25/0.55

S355J2W corten steel nechanical properties:

Grade

Min. Yield Strength Reh MPa

Tensile Strength Rm MPa

Nominal Thickness (mm)

Nominal Thickness (mm)

≤16

>16 ≤40

>40 ≤63

>63 ≤80

>80 ≤100

>100 ≤150

>3

>3 ≤100

>100 ≤150

S355J2W

355

345

335

325

315

295

510/680

470/630

450/600

Delivery Time: 30days
Payment Item: L/C, TT
Trade Terms: FOB, CFR or CIF

Certificate: ABS, DNV, BV, LR, GL, CSS, KR, NK,RINA, TUV, CE, ISO, and so on.

S355J2W corten steel services: Cutting, Painting, Pretreatment, Ultrasonic Test, Third Party Inspection, and so on.

S355J2W corten steel delivery condition: Hot rolled, CR, Normalized, Quenched, Tempering, TMCP.

Benefits of Using S355J2W
1. Excellent impact strength.
2. Ideal for heavy use or in low temperature.
3. Can be used in–situ without the need for expensive treatment or painting over time.
4. Popular material with architects for use in steel sculptures and modern structures due to aesthetic appeal.

Thanks a lot for your interesting on our S355J2W corten steel. Any need in S355J2W corten steel price, please feel free to contact us by email or calling to us. We will reply you in the first time.
