S235J0W steel plate is mainly used in hard weather owning to its property for resisting corrosion. With the minimum yield strength 235 Mpa, and the tensile strength for the thickness belows 100mm shall be within 360 to 510 Mpa.
More informational about S235J0W steel plate, please see the following:
S235J0W steel plate specification:
Steel Grade:S235J0W
Steel Standard: EN 10025-5
Thickness:2mm-450mm
Width:1000mm-4200mm
Length:3000mm-18000mm
S235J0W steel surface treatment: Shot blasting and painting or coated.
S235J0W steel chemical composition:
|
C |
Si |
Mn |
P |
S |
N |
Cr |
Cu |
|
0.13 |
0.40 |
0.20-0.60 |
0.035 |
0.035 |
0.009 |
0.40-0.80 |
0.25-0.55 |
S235J0W steel Mechanical Properties:
|
Grade |
Min. Yield Strength Mpa |
Tensile Strength MPa |
Impact |
||||||||
|
S235J0W |
Nominal Thickness (mm) |
Nominal Thickness (mm) |
degree |
J |
|||||||
|
Thick mm |
≤16 |
>16 ≤40 |
>40 ≤63 |
>63 ≤80 |
>80 ≤100 |
>100 ≤150 |
≤3 |
>3 ≤100 |
>100 ≤150 |
0 |
27 |
|
S235J0W |
235 |
225 |
215 |
215 |
215 |
195 |
360-510 |
360-510 |
350-500 |
||
S235J0W steel main application:
S235J0W steel is used for shipping containers,steel bridges,vessels and tanks for preventing atmospheric corrosion usage.
As a professional S235J0W steel plate supplier, we promise we can offer you the qualified steel. Besides that, we could promise the delivery time and the competitive price. Any need in S235J0W steel plate price or S235J0W steel technical conditions, please contact us freely.
